LCD Display Thermal Imaging Thermometer , Red Color Imaging IR
Thermometer
Product Description
IR Thermal Imagers are designed with infrared detector (80*60 pixel
, as the core and supported with high-quality optical lens,
ease-of-use operating system. It is precise to measure, clear to
view on images, easy to carry with and offers a price you can
totally afford. Choosing a UTi80 means a significant work
effectiveness and high temperature measurement accuracy, which is
especially a perfect choice for users who are already used to
point-contact thermometers.
Applicable industries:electric
power,construction,electronics,smelting,energy,railway,automobile,petrochemical.
Specifications
| Specifications | |
| Model | UTi80 | UTi100 | UTi160A |
| Sensor Type | Uncooled Focal Plane Arrays |
| Resolution | 80 x 60 | 100 x 80 | 160*120 |
| View of View / Minimum Focus Distance | 10°×7.5°/0.1m | 12°×9.4°/0.1m | 20°×15°/0.1m |
| Spatial Resolution (IFOV) | 2.2mrad |
| Image Mode | Infrared |
| Focus | Manual |
| Infrared Spectral Band | 8~14um |
| NETD | ≤0.08℃@30℃ |
| Temperature Range | -20℃~300℃ |
| Accuracy | ±2°C or ±2% (whichever is greater) |
| Features |
| Display Type | 2.8"TFT LCD; Ratable |
| Palettes | Iron, Iron-Invert, Rainbow, Feather, Grey, Grey Inverted |
| Images Adjustable | Auto/Manual |
| Image Format | *·UIR |
| Video Output | Support: PAL(50Hz) or NTSC(60Hz) (socket selection required) |
| Measurement Mode | Movable Spot, Area(MAX,MIN) |
| Parameters Setting | Emissivity, Distance, Temperature, Relative Humidity |
| Self Temperature Calibration | Every 60 Seconds |
| High/Low Temperature Alarm | √ |
| Laser Pointer | √ |
| Image Capture | √ |
| Image Storage | 2GB SD Card |
| Temperature Units | ℃/℉ |
| Support Languages | English/Simplified Chinese |
| Factory Setting | √ |
| Power Mode | Standard / Power Saving |
| Analyzing Software | Standard Version |
| Water Proof Rating | IP54 |
| Impact/Vibration | 25G/2G |
Consideration
1. During the installation and use of the product, all electrical
safety regulations must be strictly observed.
2. Please make sure that the product is installed firmly.
3. If the product does not work properly, please contact the
after-sales service. Do not disassemble or modify the product in
any way. (The company does not assume any responsibility for
problems caused by unauthorized modification or repair.
4. Do not immerse the product in water.
5. If the equipment does not work properly, please do not
disassemble it for repair, otherwise it will affect the equipment
warranty.
6. Avoid extreme or extreme environments such as extreme high
temperature (or low temperature), high humidity, vibration,
radiation, and chemical corrosion during installation and use.
